Fig.IN 914EBH

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, bronze disc, vulcanized EPDM liner, lever operated, mounting between flanges PN10, Fig.IN 914EBH.

Fig.IN 914EBV

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, bronze disc, vulcanized EPDM liner, bare shaft, mounting between flanges PN10, Fig.IN 914EBV.

Fig.IN 914EBW

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, bronze disc, vulcanized EPDM liner, cast iron gearbox, mounting between flanges PN10, Fig.IN 914EBW.

Fig.IN 914ERH

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, AISI 316 disc, vulcanized EPDM liner, lever operated, mounting between flanges PN10, Fig.IN 914ERH.

Fig.IN 914ERV

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, AISI 316 disc, vulcanized EPDM liner, bare shaft, mounting between flanges PN10, Fig.IN 914ERV.

Fig.IN 914ERW

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, AISI 316 disc, vulcanized EPDM liner, cast iron gearbox, mounting between flanges PN10, Fig.IN 914ERW.

Fig.IN 914NBH

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, bronze disc, vulcanized NBR liner, lever operated, mounting between flanges PN10, Fig.IN 914NBH.

Fig.IN 914NBV

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, bronze disc, vulcanized NBR liner, bare shaft, mounting between flanges PN10, Fig.IN 914NBV.

Fig.IN 914NBW

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, bronze disc, vulcanized NBR liner, cast iron gearbox, mounting between flanges PN10, Fig.IN 914NBW.

Fig.IN 914NBWW

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, bronze disc, vulcanized NBR liner, watertight cast iron gearbox, mounting between flanges PN10, Fig.IN 914NBWW.

Fig.IN 914NRH

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, AISI 316 disc, vulcanized NBR liner, lever operated, mounting between flanges PN10, Fig.IN 914NRH.

Fig.IN 914NRV

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, AISI 316 disc, vulcanized NBR liner, bare shaft, mounting between flanges PN10, Fig.IN 914NRV.

Fig.IN 914NRW

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, AISI 316 disc, vulcanized NBR liner, cast iron gearbox, mounting between flanges PN10, Fig.IN 914NRW.

Fig.IN 914NRWW

Data Sheet

PN10 lug type butterfly valve, GGG-40 body, AISI 316 disc, vulcanized NBR liner, watertight cast iron gearbox, mounting between flanges PN10, Fig.IN 914NRWW.

Other executions on request.
