Knife gate valves wafer type

BACK TO PRODUCTS

Fig.IN 154

Data Sheet

PN10 knife gate valve, cast iron GG-25 body, AISI 316 gate, rising stainless steel spindle, non-rising GG-25 handwheel, steel plates, NBR seat, packing gland, suitable for flanges
PN10, Fig.IN 154..

Fig.IN 154N

Data Sheet

PN10 knife gate valve, nodular cast iron GGG-40 body, AISI 316 gate, rising stainless steel spindle, non-rising GG-25 handwheel, steel plates, NBR seat, packing gland, bi-directional, suitable for flanges PN10, Fig.IN 154N.

Fig.IN 154R

Data Sheet

PN10 knife gate valve, stainless steel CF8M body, AISI 316 gate, rising stainless steel spindle, non-rising handwheel, … plates, NBR seat, packing gland, bi-directional, steel bonnet, suitable for flanges PN10, Fig.IN 154R.

Fig.IN 155

Data Sheet

PN10 knife gate valve, cast iron GG-25 body, AISI 316 gate, non-rising stainless steel spindle, steel plates, NBR seat,
packing gland, bi-directional, suitable for flanges PN10, Fig.IN 155.

Fig.IN 155N

Data Sheet

PN10 knife gate valve, nodular cast iron GGG-40 body, AISI 316 gate, non-rising stainless steel spindle, steel plates, NBR seat, packing gland, bi-directional, suitable for
flanges PN10, Fig.IN 155N.

Fig.IN 155R

Data Sheet

PN10 knife gate valve, stainless steel CF8M body, AISI 316 gate, non-rising stainless steel spindle, … plates, NBR seat,
packing gland, bi-directional, suitable for flanges PN10, Fig.IN 155R.

Other executions on request.
